SANQTID TD-S6 ميكروسكوب
ميكروسكوب SANQTID TD-S6
1- الزوم 0.65/5.8 2 - يمتلك قاعدة مساحتها 260*380 3 - العدسة العينية 10X/22MM 4 - داعم كاميرا 5 - عدسات الميكروسكوب عدسات زجاج بيور خالص 6 - الميكروسكوب بجميع مشتملاته عدسة الكاميرا CTV ، عدسة تكبير 0.7 أو 0.5 ، ليد إضاءة
| brand |
Sanqiang TEDA |
|
| model |
TD-6S-4KHU |
|
| Lenses |
Main tube magnification |
0.65-5.8X |
| eyepiece |
WF10X/23MM |
|
| Optical magnification |
6.5-58X |
|
| Working distance |
100mm |
|
| Pupillary distance range |
52-76mm |
|
| Bracket |
Focus bracket |
Lifting range: 50 mm |
| Lighting |
LED adjustable light source |
|
| Base column |
Base : 375*255mm Metal column : Height 260mm φ 32mm |
|
| camera |
Lens mount |
Standard C/CS interface |
| power supply |
DC-12V/1A |
|
| sensor |
1/ 1.8 ” CMOS sensor SONY-IMX678 |
|
| Pixel size |
2.0*2.0um |
|
| measurement accuracy |
0.0001MM |
|
| External devices |
HD monitor + computer |
|
| Resolution |
3840*2160P@60FPS |
|
| output method |
HDMI+UVC dual interface |
|
| Storage |
External USB flash drive / photography / measurement |
|
| color |
Color / Black and White |
|
| Crosshairs |
Support multiple sets of vertical / horizontal lines, colors, and positions can be adjusted arbitrarily |
|
| Image quality adjustment |
Brightness, exposure, contrast, saturation, white balance, anti-glare, color, color adjustable |
|
| Gridlines |
The horizontal line, vertical line, and center scale line can be customized in color and thickness |
|
| Measurement functions |
Point spacing, point-line spacing, line spacing, angle, arc, parallel lines, circle, circle center distance, point center distance, line center distance, rectangle |
|
| Camera Features |
Photo, video, preview, automatic edge detection, electronic zoom in / out, freeze, anti-reflection, exposure, white balance, measurement, magnification display |
|
